Bruker HYPERION User Manual

161
Bruker Optik GmbH HYPERION User Manual
A Specifications
A.1 HYPERION microscope
A.2 Objectives
Parameter HYPERION 1000/2000 HYPERION 3000
Dimensions
Width: 38 cm + 7 cm coupling unit
Depth: 60 cm
Height: 82 cm with video camera
Width : 38 cm + 17 cm coupling unit
Depth
: 80 cm
Height : 92 cm with video camera
Weight ca. 35 kg ca. 45 kg
Spectral range
Standard: 12,000 to 600 cm
-1
Optional: 25,000 to 100 cm
-1
(precondition: FT IR spectrometer being equipped with the corresponding
optical components allowing these spectral range options)
Spectral
resolution
depends on the FT IR spectrometer coupled to the microscope
Area covered by
the measure-
ment
Optimized for a diameter of 250 µm;
Minimum diameter of 10 µm with the standard objective
Ambient
requirement
Ambient temperature range: 18°C - 30°C (64°F - 86°F)
Temperature variations (during a measurement): max.
± 1°C
Humidity (non condensing): 70% (relative humidity)
Installation site: in a closed room, 2000 m above sea level
Power supply Voltage: 100 - 240 VAC ± 10%; 50 - 60 Hz
Power consumption (basic instrument): 200 W
Electrotechnical
data
Overvoltage category: II according to EN 61010-1 or IEC 60664-1
Pollution degree: 2 according to EN 61010-1 or IEC 60664-1
Protection class: I according to IEC 61140


Objective Objective
magnification
Visible
magnification
Numerical
aperture
Working
distance*
(in mm)
4x objective (VIS) 4x 40x 0.1 21
40x objective (VIS) 40x 400x 0.65 0.6
15x objective (IR) 15x 150x 0.4 24
