Bruker HYPERION - Heating; Freezing Sample Stage THMS600 (Linkam)

164
HYPERION User Manual Bruker Optik GmbH
Specifications A
FPA detectors for HYPERION 3000
The FPA
1
detectors listed in the table below are multi-element detectors.
A.6 Heating / freezing sample stage THMS600 (Linkam)
1. FPA - Focal Plane Array detector
Detector Number of
detector elements
Spectral range Mode of cooling /
Nominal hold time
photovoltaic MCT
FPA detector
16,384 elements
(square arrangement of
the elements:
128 x 128)
4,500 - 900 cm
-1
with liquid N
2
typical hold time when in
use: 8 h
typical hold time when not in
use: 20 h
photovoltaic MCT
FPA detector
1,024 elements
(square arrangement of
the elements: 32 x 32)
4,500 - 900 cm
-1
with liquid N
2
typical hold time when in
operation: 8 h
typical hold time when not in
operation 20 h
photovoltaic MCT
FPA detector
4,096 elements
(square arrangement of
the elements: 64 x 64)
4,500 - 900 cm
-1
with liquid N
2
typical hold time when in
operation: 8 h
typical hold time when not in
operation 20 h
Parameter Specification
Temperature range: -196°C to 600°C
Heating rates: between 0.1 (min.) and 130°C/min (max.)
Temperature stability: < 0.1°C
Heating element:
Silver block (ensures high thermal conductivity and allows
for extremely sensitive temperature measurements)
Stage body dimensions: 137 mm x 92 mm x 22 mm
Stage is dimensioned for:
sample diameter: 22 mm (max.)
sample thickness: 1.5 mm (max.)
Positioning range: 16 mm in x-direction and 16 mm in y-direction
Sample area: 22 mm diameter within the stage unit
Required working distance: > 4.5 mm
Spectral range: visible (quartz window)
