Brunswick StringPin - String Pinsetter Motor Power Cable - Rear Mount (55-143067-XXX); String Pinsetter Switch Cluster EXT Cable - Rear Mount (55-143068-XXX); String Pinsetter DC Pinlight Cable (55-143069-000)

Section7:Cables 7-5
4 (GRN/YEL)
3 (BLACK 3)
1 (BLACK 1)
2 (BLACK 2)
BOTH ENDS
(1)
TO
STRINGPIN
CONTROLLER
(1)
TO
STRINGPIN
MOTOR
(POWER)
String Pinsetter Motor Power Cable - Rear Mount (55-143067-XXX)
(1) TO STRINGPIN CONTROLLER (2) TO STRINGPIN MOTOR (POWER)
2
4
8
9
1
3
7
5
10
6
BROWN
GREEN
YELLOW
RED
BROWN
WHITE
BLACK
BLUE
VIOLET
ORN(PINK)
HOME SW.
PINS UP SW.
PIN SOLENOID SW.
MECHANIC SW.
TANGLE SW.
GROUND
MECHANIC SW.
+24VDC (TROUBLE LIGHT)
TROUBLE LIGHT
MOTOR OVERLOAD SW.
2
4
8
9
1
3
7
5
10
6
BROWN
GREEN
YELLOW
RED
BROWN
WHITE
BLACK
BLUE
VIOLET
ORN(PINK)
(2)
TO
STRINGPIN
CONTROLLER
(1)
TO
EXTERNAL
INPUT
String Pinsetter Switch Cluster EXT Cable - Rear Mount (55-143068-XXX)
(1) TO EXTERNAL INPUT (2) TO STRINGPIN CONTROLLER
1
2
3
BLK(BRN)
GRN
4
+24 VDC
POWER ON
+24 VDC
BLACK LIGHT
RED(YLW)
2
1
PINLIGHT
2
1
3
WHT
BLACK LIGHT
BLK(BRN)
RED(YLW)
GRN
WHT
(1)
TO
STRINGPIN
CONTROLLER
(2)
TO
PIN LIGHT
(3)
TO
BLACK LIGHT
String Pinsetter DC Pinlight Cable (55-143069-000)
(1) TO STRINGPIN CONTROLLER (2) TO REAR MECHANIC’S (3) TO FRONT MECHANIC’S STOP SWITCH
STOP SWITCH
