Brunswick StringPin - Second Ball Cycle

3-46 Section 3: Pinsetter Electronics
Second Ball Cycle
To begin a cycle a bowler must throw a ball. The pinsetter reacts as follows: Refer to Figure3-37.
Start
Pinsetter Ball
Detect
All pinfall switches
in PMIs are "Open"
The Foul
Unit Triggered
Read PMI
Pinfall Switches
NO
Drive Motor
Turns "On"
Pinsetter CPU
Counts
Ball 2
Is there
a Foul?
NO
YES
Pins Up Switch
Closes
String Brake
Switch Closes
No Action
Scorer System
Scores Pinfall After
Trigg Time As Set In
The CMS System
Scorer System
Scores "Foul"
No Action
Home
Switch Closes
Drive Motor
Turns "Off"
All Pins Lower
To The Pindeck
Figure3-37.PinsetterSecondBallCycles
