PINSETTER GUARD LABELS AND SYMBOLS
The StringPin pinsetter may have guard labels that are installed to alert the operator of various
electrical and mechanical warnings throughout the pinsetter. Additionally, various symbols will be
found designating many dierent functions. Refer to Figure 2-7 and Figure 2-8 for an explanation of all
labels and symbols.
Warning/Symbol Denition
High Voltage and/or
Electrical Warning
Indicates electrical areas which
could potentially cause personal injury
or death
Mechanical
Warning
Indicates mechanical areas which
could potentially cause personal injury
or death
Pinch Point
Warning
Indicates pinch point areas which
could potentially cause personal injury
or death
Lock Out
Indicates a reminder to
turn o󰀨 AND lock out the
pinsetter power
before servicing
G
E
R
N
E
C
M
Y
E
Emergency Stop
Indicates emergency stop(s) and
direction to rotate the E-Stop push button
to return power to the pinsetters
Figure2-7PinsetterGuardLabelsandSymbols-A
