3-16 Section 3: Pinsetter Electronics
Pinsetter Options Menu
The Options Menu allows the operator to congure advanced settings for the StringPin Pinsetter. The
following is a description of the options available in the menu. Refer to Figure3-12.
NOTE: ThemenuselectionsareonlyavailablewhenbothStop/Runswitchesonthecontroller
areintheSTOPposition.
(6)
DELAY AFTER
BALL DETECT
(7)
BALL RETURN
OFF DELAY
(8)
BALL RETURN
ENERGY TIMEOUT
(10)
SAVE
(2)
LANGUAGE
SELECTION
(3)
DETANGLE
SEQUENCE
(4)
PINSETTER
OFF STATE
(5)
PINLIGHT
ALWAYS ON
(9)
BLACKLIGHT
(11)
CONTROLLER
LOCATION
(1)
SELECT FOR
OPTIONS MENU
Options
Save
Default
Figure3-12.LCDTouchscreen-OptionsMenu
