Brunswick StringPin - Main Frame

2-10 Section 2: Overview
Main Frame
The Main Frame contains the major components that make the pinsetter function. Refer to Figure2-10.
The main frame is made up of the following components:
1. String Spool and Tension Lever Assembly
2. String Wagon and Drive Assembly
3. Pin Motion Interface (PMI)
(1)
PIN MOTION
INTERFACE
(PMI)
(5)
STRING
WAGON
(3)
STRING WAGON
DRIVE ASSEMBLY
(4)
MAIN
FRAME
(2)
STRING SPOOL AND
TENSION LEVER ASSEMBLIES
25
Figure2-10.MainFrame-Components
(1) PIN MOTION INTERFACE (PMI) (2) STRING SPOOL AND (3) STRING WAGON DRIVE
TENSION LEVER ASSEMBLY
ASSEMBLIES
(4) MAIN FRAME (5) STRING WAGON
