Section 3: Pinsetter Electronics 3-1
Section 3 - Pinsetter Electronics
The electronic system for a lane pair of string pinsetters consist of a single StringPin Controller
mounted on the rear side of the pinsetter or as an option, to the front of the pinsetters. There is one
StringPin Controller box for per lane pair. Refer toFigure3-1.
(4)
STRINGPIN CONTROLLER
REAR MOUNT
(3)
MACHINE REAR
(1)
MACHINE FRONT
(2)
STRINGPIN CONTROLLER
FRONT MOUNT
Figure3-1.StringPinsetterControllerLocations
(1) MACHINE FRONT (2) STRINGPIN CONTROLLER (FRONT MOUNT) (3) MACHINE REAR
(4) STRINGPIN CONTROLLER
(REAR MOUNT)
