Why do pins fall when being spotted on my Brunswick Game?
If pins fall when being spotted on your Brunswick Game, verify nothing is on the pin deck interfering with pin spotting. Also, check the bottom of the pin for damage and check the location of the pin centering rings.
What to do if my Brunswick Game machine and accelerator will not run?
If your Brunswick Game machine and accelerator aren't running, first ensure the main switch is in the ON position. Next, confirm that the power cord is properly installed. Finally, check the circuit breaker to ensure it hasn't tripped or been turned off.
How to troubleshoot when one Brunswick Game machine does not run?
If one Brunswick Game machine isn't running, first ensure the motor stop switches on the Pinsetter for the non-running motor are turned ON. Then, check the stringpin controller LCD display for any reported errors and confirm all electrical cables are properly installed. Also, check that the de-tangle switch (under the cover at the front of the right hand pinsetter side frame) is in the closed position. Finally, make sure the “V” belt for the drive motor is not off the pulley or broken.
Why doesn't my Brunswick Game machine stop after completing a cycle?
If your Brunswick Game machine continues running after a cycle, check that the pinsetter ball detect is clean and properly adjusted. Also, inspect the magnet on the Pin Motion Interface to verify it is not stuck in line with the reed switch. Check the Reset switch on the ball rack for proper operation. Finally, check the Home Switch for proper operation and replace it if needed.
What to do if my Brunswick Game machine starts and stops when lifting pins?
If your Brunswick Game machine starts and stops when attempting to lift pins, ensure that no pins or strings are caught or restricted from moving freely. Also, check whether one or more pin strings have excessive spring tension, or if there's improper spring tension on the pinsetter motor. Verify that any replacement string has been properly installed. Observe the de-tangle switch to see if its actuator is functioning improperly and check the de-tangle switch wiring.
What should I check if the accelerator on my Brunswick Game will not run?
If the accelerator on your Brunswick Game isn't running, check the overload for the accelerator motor to make sure it is not tripped.
How to fix inaccurate pin respots on my Brunswick Game?
To correct inaccurate pin respots on your Brunswick Game, check that the strings of the pin or pins being spotted are properly tensioned. Also, check the location of the pin centering rings.
Why does my Brunswick Game pinsetter respot fallen pins when the scorer is correct?
If your Brunswick Game pinsetter respots one or more fallen pins while the scorer scores correctly, check to see that the solenoid that locks knocked over pins in the up position is functioning. Also, ensure that all pins are properly routed and free to move.
What to do if the brake in the PMI of my Brunswick Game doesn't release?
If the brake in the PMI of your Brunswick Game does not release, verify that after the first ball, the pin has a gap of approximately 80 mm from the centering cone. Open the string break manually and adjust the string tension (increase the length of the string). Ensure that the string of the affected pin moves freely and that the string brake solenoid is not constantly actuated.
How do I isolate a malfunction in my Brunswick Game machine?
To determine if the problem is in the electrical box or with the machine, exchange the electrical slide out tray with those of a pair that are working properly. If the problem follows the electrical boxes, exchange the control unit boxes. This should allow you to determine which of the boxes is causing the problem.
Explains the meaning of 'Warnings', 'Cautions', and 'Notes' used in the manual.
Informs users about the manual's purpose and assumptions about personnel training.
Outlines essential safety measures and responsibilities for working on the pinsetter.
Provides a list of critical rules and precautions for safe operation and maintenance.
Describes how the pinsetter works and the different cycles it performs during bowling.
Explains how to start a cycle and the different cycles during bowling.
Explains the meaning of status lights and the machine's power-on sequence.
Details safety guards and their warning labels/symbols.
Introduces the main subassemblies and components of the StringPin pinsetter.
Provides a general introduction to the pinsetter's electronic system.
Illustrates the electrical system and component interconnections.
Details the controller's functions, external connections, and interfaces.
Explains status indicators, start button, and pinsetter on/off switches.
Guides users through the touchscreen interface, menus, settings, and diagnostics.
Procedures for adjusting switch positions and string tension for proper operation.
Adjustments for accurate pinfall detection and slow pin setting.
Steps for adjusting the tension and alignment of the ball accelerator belt.
Explains how to align the ball detector's infrared beam with the reflector.
Covers general inspection, cleaning, lubrication, and string repair procedures.
Instructions for routing and installing new string on the pinsetter.
Procedures for replacing the pinsetter's drive motor and related components.
Wiring instructions for drive and accelerator motors.
Explains how to test and correct the rotation direction of the drive motor.
Details the lubrication schedule and procedures for various components.
Lists common issues like machine not running or cycling issues.
Details specific error codes, their causes, and how to resolve them.
Provides comprehensive tables for diagnosing and fixing various operational problems.
Wiring diagrams for PMI and switch cluster cables connecting to controller.
Diagrams for cables connecting controller to E-stop, overload, LEDs, and ball detection systems.
Wiring diagrams for motor, light, and switch connection cables.
Comprehensive wiring schematics for UL and CE versions of the controller.
Explains the meaning of 'Warnings', 'Cautions', and 'Notes' used in the manual.
Informs users about the manual's purpose and assumptions about personnel training.
Outlines essential safety measures and responsibilities for working on the pinsetter.
Provides a list of critical rules and precautions for safe operation and maintenance.
Describes how the pinsetter works and the different cycles it performs during bowling.
Explains how to start a cycle and the different cycles during bowling.
Explains the meaning of status lights and the machine's power-on sequence.
Details safety guards and their warning labels/symbols.
Introduces the main subassemblies and components of the StringPin pinsetter.
Provides a general introduction to the pinsetter's electronic system.
Illustrates the electrical system and component interconnections.
Details the controller's functions, external connections, and interfaces.
Explains status indicators, start button, and pinsetter on/off switches.
Guides users through the touchscreen interface, menus, settings, and diagnostics.
Procedures for adjusting switch positions and string tension for proper operation.
Adjustments for accurate pinfall detection and slow pin setting.
Steps for adjusting the tension and alignment of the ball accelerator belt.
Explains how to align the ball detector's infrared beam with the reflector.
Covers general inspection, cleaning, lubrication, and string repair procedures.
Instructions for routing and installing new string on the pinsetter.
Procedures for replacing the pinsetter's drive motor and related components.
Wiring instructions for drive and accelerator motors.
Explains how to test and correct the rotation direction of the drive motor.
Details the lubrication schedule and procedures for various components.
Lists common issues like machine not running or cycling issues.
Details specific error codes, their causes, and how to resolve them.
Provides comprehensive tables for diagnosing and fixing various operational problems.
Wiring diagrams for PMI and switch cluster cables connecting to controller.
Diagrams for cables connecting controller to E-stop, overload, LEDs, and ball detection systems.
Wiring diagrams for motor, light, and switch connection cables.
Comprehensive wiring schematics for UL and CE versions of the controller.
