Brunswick StringPin - Work Area 2 - Ball Accelerator and Standing Platforms

Section 2: Overview 2-27
Work Area 2 - Ball Accelerator and Standing Platforms
Infrequently, a pinsetter stop or maintenance requires access further into the machine. For situations
that cannot be performed from Work Area 1, Work Area 2 can be used. Refer to Figures 2-27 and 2-28.
This area may be used for such activities as:
1. Correcting Pinspotting Issues
2. Correcting Ball Return Stop - Pit Area
CAUTION: When accessing work area 2, the main power switch on the
StringPin Controller must be locked in the o position using a suitable locking
mechanism
(2)
WORK AREA 2
(1)
ACCESS STEPS
(1)
ACCESS STEPS
(2)
WORK AREA
2
Figure 2-27. Machine Work Area 2 - Ball Accelerator and Standing Platforms
(1) ACCESS STEPS (2) WORK AREA 2
(1) HANDRAILS
(2)
WORK
AREA 2
(2)
WORK AREA 2
Figure 2-28. Machine Work Area 2 - Ball Accelerator and Standing Platforms
(1) HANDRAILS (2) WORK AREA 2
