Section 3: Pinsetter Electronics 3-31
Rear Mounted Pinsetter Controllers
LED
INDICATOR
FUSE
(5x20mm)
(3.15A, 250V Fast)
DESCRIPTION
Odd (Left) Lane
D8 F1
1,2,3 PMI Solenoids
Ball Door Solenoid (Optional)
D45 F3 4,5,6 PMI Solenoids
D54 F6 7,8,9 PMI Solenoids
D85 F8
10 PMI Solenoid
1/2 Ball Light (Masking Unit)
String Wagon Motor Control
Even (Right) Lane
D9 F2
1,2,3 PMI Solenoids
Ball Door Solenoid (Optional)
D46 F5 4,5,6 PMI Solenoids
D55 F7 7,8,9 PMI Solenoids
D86 F9
10 PMI Solenoid
1/2 Ball Light (Masking Unit)
Trouble Lights (Both Lanes)
String Wagon Motor Control
Ball Lift Motor Control
Common
D50 F4
CPU PCB Power
High Voltage PCB Power
Ball Detect Power
Power - Machine Switches
Touchscreen LCD Power
Ball Accelerator Motor Control
D/C Pinlight Power
D68, D95 F4
5VDC Power (Ball Detector)
3.3 VDC Power
D89 F4 CPU Heartbeat
D90 F4 Transmit - Scorer Communication
D91 F4 Receive - Scorer Communication
D93 F4 Power - Scorer Communication
D92 F4
Direction - Scorer Communication
(On When Transmitting)
Figure3-23.CPUPCBVersionB-LEDandFuseChartForREARMountedControllers
