323009 - apartment interFace
Typical Wiring Diagram 1
Remarks. To power this device you can either use the
auxiliary power supply or the standard power supply (We
recommend using the auxiliary Power supply). If the power
consumption of five handsets is not more than the supply
provided by one power supply, then these five handsets can
all be set as the master handsets.
System accessories functions overview
323002
323010
HANDSET HANDSET HANDSET HANDSET HANDSET
323009
323015
322020
To HANDSET 1 To HANDSET 2
To HANDSET 4
System output
(connect next 323002 input)
System input
(connect last 323002 output)
To Next Page
