D45 VIDEO DOOR ENTRY SYSTEM
coDe For the conFiguration place
F F I I #I #I
Configuration methods using the pushbuttons
1. Enter into the configuration status: In standby, press key
(S2) for 2 seconds to enter configuration mode, the CFG
indicator will be on (If the configurator is fitted with a
resistor or the pushbuttons are incorrectly configured,
access to configuration mode is not possible).
2. Enter the configuration place code (to select a certain
place at the configurator): press the S2 key to reach
the desired number. At every pressure the code will be
increased by one 1 (no pressure will give 1) and the CFG
indicator will flash once.
3. Confirm the configuration place code: Press the S1 key
and the CFG indicator will flash quickly twice. Then it
emit an extended flash to and enter value configuration
mode.
4. Enter the configuration place value: Press the S2 key
(defaulted at 0). Press once and the value will be
increased by 1, the CFG indicator flashing quickly twice.
5. Confirm the configuration place value: Press the S1 key
and the CFG indicator will flash quickly twice; than it
flashes slowly twice, the value is set.
6. Set the next place: If you need to set the value of other
configuration places, press S2 and the CFG indicator will
flash 3 times. Then continue from point (2).
7. End the configuration: Press the S1 key to exit
configuration mode. If the procedure has been successful
the CFG will flash once and then come on steady. The
new configuration is now available. If the procedure
fails (for example, a certain configuration value is bigger
than 9), the CFG indicator will go off and then come
back on using the old configuration. If the configuration
value is logically wrong (such as II>#II), then on reset
the CFG indicator will flash quickly, indicating wrong
configuration and pushbutton operation will stop.
In this case connect the non-zero (1 to 9) resistor to
the configurator and repower to clear all the values
configured using the pushbuttons. Remove the resistor,
repower and reset following the above steps. If during
the operation no pushbutton is pressed for 10 seconds,
the unit will automatically exit the configuration status
and the CFG indicator will go off.
Methods for viewing the configuration
(You can only view the information configured with
the pushbuttons or RS232 ).
1. Switch to view status: In standby, press the S1 key
for 2 seconds and the CFG indicator will flash slowly
and enter configuration view mode (This status is
not accessible in case of wrong configuration).
2. Enter the configuration code (to select a certain
place at the configurator): press the S2 key to
increase the numbers. At every pressure the code
will be increased by one 1 (no pressure will give 1)
and the CFG indicator will flash slowly twice.
3. Read the configuration value: Press the S1 key and
the CFG indicator will flash. The number of times it
will flash will depend on the size of the value (For
example, if the reading result is 0, it won’t flash; if
it’s 1, it will flash once, and if 2, it will flash twice,
and so on), and then move to the next step.
4. With the CFG indicator off, it will exit the
configuration view status: If during the operation
no pushbutton is pressed for 10 seconds, the unit
will automatically exit the status and the CFG
indicator will go off.
