Bticino D45 Technical Guide

85
D45 VIDEO DOOR ENTRY SYSTEM
recommenDeD pws solution anD relateD conFiguration
NO. INSTALLATION
STATUS OF
SYSTEM
POWER SUPPLY
SOLUTION
CONFIGURATION WHEN POWER SUPPLY IS SYSTEM POWER SUPPLY
(impedance switch of Power supply must be ON)
CONFIGURATION OF POWER SUPPLY & APOWER SUPPLY
when Power supply is assistant power supply (impedance switch of
Power supply must be OFF)
alarm Small EP
CF1
~
CF3
(NNN)
CF4
~
CF11
CF12
(Type)
CF13
(ASR)
CF14
(M)
CF15
(LE)
CF1
~
CF3
(NNN)
CF4
~
CF11
CF12
(Type)
CF13
(ASR)
CF14
(M)
CF15
(LE)
1 None None 1 X X X X X X
Under these four condition, using auxiliary power supply no need
congurate
2 None None 1 X X X X X X
3 have None 1 X X X X X X
4 have None 1 NNN X 1 0.2~9 1 X
5 None have 2 NNN √ 1 1 0/1 X X √ 2 1 0/1 X
6 None have 2 NNN √ 1 1 0/1 X X √ 2 1 0/1 X
7 have have 2 NNN √ 1 0.2~9 0/1 X X √ 2 0.2~9 0/1 X
8 have have 2 NNN √ 1 0.2~9 0/1 X X √ 2 0.2~9 0/1 X
Note:
(X:) It means no configurator is needed and the configuration position is 0; others need a configurator with corresponding value.
(√:) It means configuration is needed. For the configuration procedure refer to the system configuration chapter.
CF1~CF15 is the configuring position for 323005. For the detailed meaning and configuration method please check the system configuration chapter.
