Bticino D45 Technical Guide

91
D45 VIDEO DOOR ENTRY SYSTEM
Table 5: Case 1 to Case 4, the quantity of devices managed by 323005(Power supply)
How many apartments
on every oor
HANDSET
Case 5 Case 6 Case 7 Case 8
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
2 apartments/oor
(Don’t use extra power
cable)
4[*2] max:2 floor 8[*2] max:4 floor 36 max: 18 floors 8 max: 4 floors
2 apartments/oor
(use extra power cable)
8[*2] max: 4 floors 90 max: 45 floors 8 max: 4 floors
4 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 56 max: 14 floors 8 max: 2 floors
8 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 72 max: 9 floors 8 max: 1 floor
12 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 76 max: 7 floors 8 max: 1 floor
16 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 5 floors 8 max: 1 floor
20 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 4 floors 8 max: 1 floor
24 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 4 floors 8 max: 1 floor
28 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 3 floors 8 max: 1 floor
32 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 3 floors 8 max: 1 floor
36 apartments/oor
4[*2] max: 1 floor 8[*2] max: 1 floor 80 max: 3 floors 8 max: 1 floor
Table 6: Case 9 to Case 12, the quantity of devices managed by 323005(Power supply)
How many apartments
on every oor
HANDSET
Case 9 Case 10 Case 11 Case 12
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
Total Qty of
handsets
Floor limit
2 apartments/oor
(Don’t use extra power
cable)
16 max: 8 floors 16[*2] max: 16 floors 4[*3] max: 1 floor 12[*1] max: 6 floors
2 apartments/oor
(use extra power cable)
16 max: 8 floors 36[*3] max: 6 floors 4[*3] max: 1 floor 12[*1] max: 6 floors
4 apartments/oor
16 max: 4 floors 24[*3] max: 4 floors 4[*3] max: 1 floor 12[*1] max: 3 floors
8 apartments/oor
16 max: 2 floors 32[*3] max: 3 floors 4[*3] max: 1 floor 12[*1] max: 2 floors
12 apartments/oor
16 max: 2 floors 36[*3] max: 3 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
16 apartments/oor
16 max: 1 floor 36[*3] max: 2 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
20 apartments/oor
16 max: 1 floor 36[*3] max: 2 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
24 apartments/oor
16 max: 1 floor 36[*3] max: 2 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
28 apartments/oor
16 max: 1 floor 36[*3] max: 2 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
32 apartments/oor
16 max: 1 floor 36[*3] max: 2 floors 4[*3] max: 1 floor 12[*1] max: 1 floor
36 apartment/oor 16 max: 1 floor 36[*3] max: 1 floor 4[*3] max: 1 floor 12[*1] max:1 floor
