2002 Buell S3T: Fuel System 4-79
HOME
Figure 4-64. Bank Angle Sensor Circuit
b0540x4x
ABCD 12
AB
FR
C
12
Electronic Control Module
(ECM)
Connector [10] Connector [11]
Rear
Fuel
Injector
[85]
Front
Fuel
Injector
[84]
Fuel
Pump
CBA
b0526x4x
Bank
Angle
Sensor
[134]
Ignition Coil [83]
GY
Lt GN/GY
BK
GY GY
Lt GN/GY
BK
GY
GY
R
R
R/GY
R/BK
R/GY
R/BK
R/BK
R/BK R/BK
GY/O
Ignition 20A
Memory 15A
Spare 15A
Lights 15A
Instruments 15A
Accessory 15A
Ignition
Switch
[33]
Engine Stop
Switch [22]
TN/W
Ignition Relay
W/BK
GY/O
To Main Circuit
Breaker
To Starter
Interlock Circuit
GY
GY
[86]
Table 4-25. Wire Harness Connectors in Figure 4-64.
NO. DESCRIPTION TYPE LOCATION
[10] ECM (black) 12-place Deutsch under tail section
[134] Bank Angle Sensor 3-place Packard under tail section, right side
