Code 44 Test (Part 1 of 2)
Is bank angle
sensor connected?
YES
Disconnect bank angle sensor
connector [134]. Measure voltage on [134]
between Socket A (Lt GY/GN) and
Socket B (BK). What is voltage?
NO
Reconnect. Clear
codes and cycle
ignition key.
Recheck for codes.
Repair short to
voltage on
Lt GY/GN wire.
4.0-6.0 volts
Measure voltage between Socket C (GY)
and Socket B (BK). Is voltage 11-13 volts?
11-13 volts 0 volts
Go to Code 44 Test
(Part 2 of 2).
YES
Is bank
angle sensor
correctly installed?
NO
Repair open in
GY wire between
[134] and
harness.
YES
Are ferrous metals located within
0.25 in. (6.4 mm) of sides, face or
top of bank angle sensor?
NO
Install bank angle sensor
properly. See 4.33 BANK
ANGLE SENSOR.
YES
Return to original
configuration.
NO
STOP
Replace bank angle sensor.
See 4.33 BANK ANGLE
SENSOR.
1
7971
7972
7975
7976
To Next Page
