1-8 2002 Buell S3T: Maintenance
HOME
Front fork oil (1.15 FRONT FORK)
FRONT WHEEL SUPPORT STAND (Part No. B-41395-A)
& LIFT ADAPTER (Part No. B-42426-1)
PRO-LEVEL OIL GAUGE (Part No. B-59000A)
R Fork oil
HYDRAULIC FORK OIL, TYPE E (Part No. HD-99884-80
)
Capacity
15.36 oz. (450 cc)
Fluid level
(Standard) 3.15 in. (80 mm) from top with fork fully compressed
(Maximum) 2.36 in. (60 mm) from top with fork fully compressed
(Minimum) 4.33 in. (110 mm) from top with fork fully compressed
Spark plugs (1.17 SPARK PLUGS)
I R I R I R Spark plug type
No. 10R12
Spark plug gap
0.038-0.043 in. (0.97-1.09 mm)
Lubricant
LOCTITE ANTI-SEIZE LUBRICANT
Torque
11-18 ft-lbs (15-24 Nm)
Air cleaner filter (1.18 AIR CLEANER)
I R R R R R R Check more often in dusty conditions.
Throttle control cable (2.24 THROTTLE CONTROL) IL L L L L L L Check for damage and freeplay.
Throttle control grip sleeve (2.24 THROTTLE CONTROL) IILIILIILIILIILIILIIL Controls must be smooth and not binding
Front brake and clutch hand levers (Section 2) L L L L L L L Check for damage and freeplay.
Engine low and fast idle speed (1.19 IGNITION TIMING) IIIIIIIIIIIIII Regular idle
850-1050 RPM
Ignition timing (1.19 IGNITION TIMING)
TIMING MARK VIEW PLUG (Part No. HD-96295-65D)
BREAKOUT BOX (Part No. HD-42682)
HARNESS CONNECTOR TEST KIT (Part No. HD-41404)
I I I I I I
Fuel filter
(4.38 INLINE FUEL FILTER)
R See Section 4. Make sure arrow on filter points in direction of fuel flow.
Calibrate (re-zero) Throttle Position Sensor (TP Sensor) (4.35 THROT-
TLE POSITION SENSOR)
X See Section 4, THROTTLE POSITION SENSOR, Calibration
Table 1-3. Regular Maintenance Intervals
SERVICE OPERATIONS
AND SPECIAL TOOLS
