2002 Buell S3T: Chassis 2-3
HOME
Header Support Mounting
Bolt (Upper)
30-33 ft-lbs 41-45 Nm
Mirror Mounting Nuts 7-10
in-lbs
0.8-1.1 Nm metric
Muffler Clamp 40-45 ft-lbs 54-61 Nm discard after use
Muffler Mounting Bolts (Front) 22-24 ft-lbs 30-33 Nm
Muffler Mounting Bolts (Rear) 22-24 ft-lbs 30-33 Nm
Muffler Support Mounting
Bolt (Rear)
12-15 ft-lbs 16-20 Nm
Rear Axle Nut 66-73 ft-lbs 90-99 Nm metric
Rear Brake Caliper Banjo
Bolt
16-20 ft-lbs 22-27 Nm
metric
Rear Brake Caliper Bleeder
Valve
3-5 ft-lbs 4-7 Nm
metric
Rear Brake Caliper Mounting
Screw (Large)
18-22 ft-lbs 24-30 Nm
LOCTITE THREADLOCKER 272 (red), metric
Rear Brake Caliper Mounting
Screw (Small)
14.5-18 ft-lbs 20-24 Nm
LOCTITE THREADLOCKER 272 (red), metric
Rear Brake Lamp Switch 7-8 ft-lbs 10-11 Nm LOCTITE PIPE SEALANT WITH TEFLON
Rear Brake Line Clamp Screw 10-12 ft-lbs 14-16 Nm
Rear Brake Reservoir
Mounting Screw
12-15
in-lbs
1-2 Nm
Rear Brake Rotor Screws 35-40 ft-lbs 48-54 Nm LOCTITE THREADLOCKER 272 (red), metric
Rear Master Cylinder Banjo
Bolt
16-20 ft-lbs 22-27 Nm
metric
Rear Master Cylinder
Mounting Screws
8-10 ft-lbs 11-14 Nm
metric
Rear Master Cylinder Rod to
Brake Pedal Screw
10-12 ft-lbs 14-16 Nm
Rear Shock Mounting Screw 30-33 ft-lbs 41-45 Nm metric
Saddlebag Support Bracket
Upper Bolt
13-17 ft-lbs 18-23 Nm
Sprocket Bolt 55-65 ft-lbs 75-88 Nm LOCTITE THREADLOCKER 272 (red)
Sprocket Cover Mounting
Screw
12-17
in-lbs
1-2 Nm
LOCTITE THREADLOCKER 243 (blue)
Sprocket Cover Screw 4-6 ft-lbs 5-9 Nm LOCTITE THREADLOCKER 222 (purple)
Swingarm Pinch Screw 27-30 ft-lbs 37-41 Nm LOCTITE THREADLOCKER 243 (blue)
Swingarm Threaded Rod
11-12 ft-lbs 15-16 Nm
LOCTITE THREADLOCKER 222 (purple), initial
torque only
Swingarm/Drive Support
Screw
20-25 ft-lbs 27-34 Nm
LOCTITE THREADLOCKER 272 (red)
Switchgear Housing Screws,
(left side)
25-33
in-lbs
3-4 Nm
metric
Switchgear Housing Screws,
(right side)
12-17
in-lbs
1-2 Nm
metric
Valve Stem Nut 42-44
in-lbs
4.7-5.0 Nm
ITEM TORQUE NOTES
