2006 Buell Lightning: Electrical 7-69
HOME
13. Remove windscreen. See 2.42 WINDSCREEN.
14. See Figure 7-89. Disconnect:
● Turn signal flasher connector [30].
● Instrument module connector [39].
● Left switch housing connector [24] and right switch
housing connector [22].
● Turn signal connectors [31].
● Headlight connector [38].
● Horn connectors [122].
● Clutch switch [95] from left switch housing.
● Front brake switch [121] from right switch housing.
15. Cut and remove cable strap (6) securing main harness to
ignition switch.
16. Disconnect wiring located under sprocket cover. See
7.26 SPROCKET COVER WIRING.
17. Remove connector from oil pressure switch [120]. Oil
pressure switch is located on front of engine. See 3.12
OIL PRESSURE INDICATOR SWITCH.
18. Disconnect intake air temperature sensor [89]. See 4.36
INTAKE AIR TEMPERATURE SENSOR.
19. Disconnect throttle position sensor [88]. See 4.37
THROTTLE POSITION SENSOR.
20. Disconnect fuel line at fuel rail.
21. Remove spark plug wires.
22. Remove any remaining cable straps and clamps secur-
ing wire harness and remove harness from front of vehi-
cle.
23. Pull the main harness out through the rear of the frame/
fuel tank assembly between the trunk pan and the rear
tire.
NOTE
Using scissors jack, raise vehicle higher to gain more clear-
ance between the trunk pan and tire.
24. Remove all push pins.
Figure 7-89. Electrical Connectors Behind Windscreen
1. Turn signal flasher connector [30]
2. Instrument cluster connector [39]
3. Right handlebar connector [22]
4. Left handlebar connector [24]
5. Turn signal connectors [31]
6. Ignition switch
7. Cable strap
8. Main harness
9. Horn fastener
10. Horn mount
11. Horn connector [122]
12. Horn
9
4
8
2
1
5
10
12
6
7
10635
3
11
5
