MicroDock II
User Manual
10
Installation
Figure 4. Base Station Connections
Table 6. Base Station Connections
a Warning
The atmosphere must be free of hazardous gas. Do not use the
base station in a hazardous area.
Follow all required National Electrical Codes (NEC) and safety
standards.
a Caution
Do not remove the battery cover while the base station is
activated.
Item Description
1
Inlet filter assembly (PURGE 1)
2
C-cell batteries (4)
3
Battery cover
4
Phillips pan head retaining screws (2)
5
MMC or SD card
6
Battery compartment
7
Charger port
8
USB port
9
Power port
10
Exhaust outlet
11
Gas cylinder
12
Demand flow regulator
13
Calibration gas hose
