MicroDock II
Installation
Note
The base station can operate from either an electrical power
source or batteries. The batteries will provide automatic
backup power if the main power fails.
1. Connect the power cord to the POWER port on the base station
and then plug the cord into an AC outlet.
To install the batteries, refer to Battery Installation
.
2. Connect the charger cord to the CHARGER port on the base
station and then plug the cord into an AC outlet (if applicable).
3. Attach all gas connections. Inlet 1 (PURGE) is configured for
ambient air and inlets 2-5 are configured for calibration/test
gases. Refer to Confirming Inlet Setup
.
4. Connect the demand flow regulator. A demand flow regulator
must be used with all gas cylinder connections.
5. Ensure the exhaust line is not connected to a negative pressure
system.
For AC main installation, a circuit breaker must be integrated in the build-
ing installation as a disconnect device for the base station.
The disconnect device must be installed in close proximity to the base
station and must be marked as a disconnecting method for the base sta-
tion.
Battery Installation
a Warning
Only change batteries in an atmosphere that is free of hazardous
gas. Failure to adhere to this warning can result in personal injury
and/or property damage.
To install batteries in the base station, refer to Figure 4.
and complete the
following:
1. Loosen the retaining screws from the battery cover. Do not
remove the retaining screws from the battery cover.
2. Remove the battery cover.
3. Insert four C-cell batteries into the battery compartment.
4. Replace the battery cover and tighten the retaining screws. Do
not over tighten the screws. Refer to Table 13.
