MicroDock II
User Manual
16
Inserting the GasAlertMicro 5/PID/IR
Note
The GasAlertMicro 5, GasAlertMicro 5 PID, and GasAlertMicro
5 IR are referenced as the GasAlertMicro 5/PID/IR.
The GasAlertMicro 5/PID/IR rechargeable battery pack can be
charged separately from the detector. Refer to Inserting the
GasAlertMicro 5/PID/IR Battery Pack.
a Caution
Infrared or intense ambient light (sun or halogen) may interfere
with the base station/detector communication.
Figure 7. Inserting the GasAlertMicro 5/PID/IR
Note
Table 9 references Figure 7 and Figure 8.
