BW Technologies MicroDock II - Calibration Results; Calibration Pass; Calibration Fail

MicroDock II
User Manual
70
3. The base station purges the N
2
before applying the CO
2
gas.
4. The base station then applies the gas to the CO
2
sensor.
5. The base station begins calibrating the remaining sensors. For
more information, refer to Automatic Datalog Download
(GasAlertMicroClip, GasAlertMax XT, and GasAlertQuattro only).
6. After calibration is complete, the base station displays the results
and performs a final purge to clear any remaining gas.
The countdown of seconds remaining displays beside Purge.
Note
After calibration, the GasAlertMicro 5/PID/IR automatically
deactivates. To bypass the automatic shutdown, remove the
detector within 15 seconds after the final purge begins.
Calibration Results
After the calibration is complete, the base station LCD displays the
results.
Calibration Pass
and Pass indicates that the calibration has passed. The detector is
now ready for use. Press
C OK to return to normal operation.
Calibration Fail
If calibration fails, displays beside the applicable gas.
Example: H2S
Pass
Fail
H2S
No gas found (H
2
S is used as an exam-
ple, this applies to all gases)
Sensor is disabled
