MicroDock II
Adding Another Docking Module
Adding Another Docking Module
If required, refer to Using the Base Station before adding a docking
module.
a Warning
Only one module can be connected at a time. Complete steps #1-
20 for each docking module that is added.
To add another docking module, refer to
• Table 13.
• Table 14.
,
• Figure 14.
,
• Figure 15.
, and
• Figure 16.
,
• and complete the following procedures:
Table 13. Torque Specifications
Table 14. Adding Another Docking Module
Housing Assembly Torque
Alligator clip 4-5 in lbs
Wall mounting plate 9-10 in lbs
Item Description
1
Phillips pan-head screw (3)
2
End plate
3
Barbed fitting ports
4
Gasket block
5
Phillips flat-head screw
6
PCB connectors
7
Bottom cover plate
