19
MicroDock II
Installation
3. Hold the battery pack (serial number label down) at a 45° angle
and insert the bottom into the detector bay.
Ensure that the connector outlets on the bottom of the battery
pack lock into place over the connector pins in the docking bay,
and then lower the top into place.
4. Lower the lid and press down until the release tabs click.
The base station beeps and the Charge Status LED lights red.
