SERVICE PROCEDURES 73
Transferring options to the new motherboard
After you verify that the new motherboard solves the problem that you are troubleshooting,
you must use the Fiery Options Utility and the one-time use dongle to transfer options to the
new motherboard.
TO TRANSFER OPTIONS TO THE NEW MOTHERBOARD
NOTE: This procedure assumes that the imagePRESS Server is fully assembled, verified in
Service Mode (see page 71), and powered off.
1. Make sure that the one-time use dongle is firmly attached to a USB port on the
imagePRESS Server and that no other dongles or USB storage devices (for example, a flash
or thumb drive) are attached to the imagePRESS Server.
The options transfer process may fail if other dongles and/or USB storage devices are
connected to the imagePRESS Server during the process.
2. Power on the imagePRESS Server.
3. Immediately insert the Fiery Options Utility CD into the DVD drive.
NOTE: The Fiery Options Utility CD must be in the DVD drive in time for the
imagePRESS Server to boot from it. If the imagePRESS Server does not boot from the
Fiery Options Utility, allow the imagePRESS Server to start up, eject the CD, turn off the
imagePRESS Server, and then repeat steps 2 and 3.
NOTE: If an error message displays, see page 76.
4. To continue, choose the Control Panel or monitor (if present) as the interface to use
throughout the option transfer process.
The first screen that displays when you start the Fiery Options Utility allows you to choose
the interface that you will use throughout the procedure. Choose an interface by selecting OK
on the Control Panel or monitor. The interface not chosen is then disabled during the option
transfer process.
Control Panel Monitor
Press OK to
continue
Options Utility
OK
Fiery Options Utility
To c o nt inue running the Fiery
Options Utility using the monitor,
keyboard and mouse, press Enter
or click OK. To continue running
the Fiery Options Utility using the
Fiery Control Panel instead, press
OK on the Fiery Control Panel.
OK
