Canon imagePROGRAF iPF765 User Manual

2
If Start imagePROGRAF Print Plug-In is displayed, click it.
3 Click Print from the imagePROGRAF Print Plug-In toolbar/ribbon.
Important
• When more than one worksheet is selected, the Printing Wizard cannot be run. Select only one worksheet and
click Print again.
If a print area is set, a confirmation message dialog box
will appear.
To print the selected area, cancel the setting of the print
area.
The Printing Wizard dialog box is displayed.
4 Click Print Selected Area.
Important
• If only one cell is selected, Print Selected Area cannot be selected.
iPF765 Print Selected Area (Excel)
User's Guide
Windows Software Print Plug-In for Office
289

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
