Canon imagePROGRAF iPF765 User Manual

A message will appear informing you that analysis is in
progress.
The Layout menu will appear automatically.
Important
• If the range selected in Excel 2007/2010 is too large, it will not be possible to analyze the data. Select a smaller
range and then run the analysis.
Note
• If data analysis requires time, a message dialog will appear. If you select No, you will return to the application.
5 Select Roll Paper Width that is set in the printer.
6 Select image size.
7 Select layout.
8 To configure Binding, click the Binding Settings button.
Refer to Configuring Binding (Excel) →P.291 for details on the procedure for configuring Binding.
Print Selected Area (Excel) iPF765
User's Guide
Windows Software Print Plug-In for Office
290

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
