Canon imagePROGRAF iPF765 User Manual

When specifying an IPv4 IP address
1
Start imagePROGRAF Device Setup Utility from the
start menu.
2 In the Device Name list displayed, select the printer to configure.
3 Choose Protocol Settings from the Printer menu.
4
Select the IPv4 tab.
5 In the Setting IP Address list, choose Manual.
6 Enter the IP address assigned to the printer and click the Set button.
7 Click OK after the Confirmation message is displayed.
8 Exit imagePROGRAF Device Setup Utility.
Note
• To configure the IP address automatically, choose Auto in the Setting IP Address list and select DHCP, BOOTP, or RARP.
• You can also specify the subnet mask and default gateway.
iPF765
Configuring the IP Address Using imagePROGRAF Device Setup Utility
User's Guide
Windows Software Device Setup Utility
309

Canon imagePROGRAF iPF765 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Storage media	HDD
Internal storage capacity	250 GB
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
