COPYRIGHT © 1998 CANON INC. CANON PC400/420/430,FC200/220 REV.0 JAN.1998 PRINTED IN JAPAN (IMPRIME AU JAPON)
CHAPTER 7 EXTERNALS/AUXILIARY MECHANISMS
7-13
Figure 7-205C
Fastons
(white harness)
Fastons
(black harness)
Fastons
(gray harness)
Door switch
2. Points to Note When Installing the
Delivery Door Switch
Caution:
When inserting the fastons into the
door switch, make sure that the
correct fastons are connected as
identified by color (Figure 7-205C).
