Canon PC430 - Page 209

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
101 - NPN
RF
UPPER MAIN BODY
1
FA9 - 2864 - 000
2
SET SCREW,M3X4
2
FB1 - 7381 - 000
2
PLATE, RETAINER
3
FB1 - 7383 - 020
1
GUIDE, PAPER PICK-UP, UPPER FC220,PC420,430
FB1 - 8861 - 000
1
GUIDE, PAPER PICK-UP, UPPER FC200,PC400
4
FB1 - 7390 - 000
2
PLATE, RETAINER
5
FB1 - 7391 - 000
1
RING, OPEN/CLOSE BRAKE
6
FB2 - 9687 - 000
1
PLATE, AE WINDOW FC220,PC420,430
7
FB2 - 9688 - 000
1
PLATE, SCANNER COVER
8
FB2 - 9691 - 000
1
SHEET, ANTI-REFLECTIVE, 1
9
FB2 - 9692 - 000
1
SHEET, ANTI-REFLECTIVE, 2
10
FB2 - 9693 - 000
1
SHEET, ANTI-REFLECTIVE, FRONT
11
FB2 - 9694 - 000
1
SHEET, ANTI-REFLECTIVE, REAR
12
FB2 - 9695 - 000
1
SHEET, ANTI-REFLECTIVE, RIGHT
13
FB4 - 0361 - 000
1
LABEL, JAM EXCEPT CHINESE
EXCEPT KOREAN
FB4 - 0369 - 000
1
LABEL, JAM CHINESE
FC2 - 9144 - 000
1
LABEL, JAM KOREAN
14
FF2 - 9929 - 000
1
CABLE, AE SENSOR FC220,PC420,430
J621
FF2 - 9930 - 000
1
CABLE, AE SENSOR FC200,PC400
J621
15
FF5 - 3676 - 000
1
FIBER, OPTIC LENS ARRAY
15A
FB1 - 7380 - 000
2
SEAL, LIGHT SHIELD
15B
FB2 - 9699 - 000
1
FILTER, AIR
16
FF5 - 6415 - 000
1
COVER, UPPER BODY FC220,PC420,430
WHITE
FF5 - 6416 - 000
1
COVER, UPPER BODY FC220,PC420
GRAY
FF5 - 6437 - 000
1
COVER, UPPER BODY FC200,PC400
WHITE
FF5 - 6438 - 000
1
COVER, UPPER BODY FC200,PC400
GRAY
16A
FB2 - 9696 - 000
1
SHEET, ANTI-REFLECTIVE, UPPER
17
FF5 - 6424 - 000
1
BLOCK, FRONT SPACER
17A
FB4 - 0051 - 000
1
SHEET, SHARP CUT
18
FF5 - 6425 - 000
1
BLOCK, REAR SPACER
