Canon PC430 - Page 210

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
101 -
18A
FB4 - 0051 - 000
1
SHEET, SHARP CUT
19
FG5 - 9608 - 000
1
UPPER MAIN BODY SUB UNIT FC220,PC420,430
FG5 - 9477 - 000
1
UPPER MAIN BODY SUB UNIT FC200,PC400
20
FS5 - 2337 - 000
1
SPRING, COMPRESSION
21
FS5 - 2358 - 000
2
SPRING, COMPRESSION FC220,PC420,430
22
FS5 - 2359 - 000
1
SPRING, COMPRESSION
23
FS6 - 2168 - 000
1
SPRING, COMPRESSION
24
WG3 - 0055 - 000
1
PHOTO-DIODE, BS520 FC220,PC420,430
25
WG3 - 0055 - 000
1
PHOTO-DIODE, BS520
501
XB4 - 7300 - 509
1
SCREW,TAPPING,TRUSS HEAD,M3X5
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
101-3
