Canon PC430 - Page 213

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
102 - NPN
RF
LOWER MAIN BODY FC220,PC420,430
1
FA9 - 2568 - 000
1
SCREW,MACH.,TRUSS HEAD 100V
2
FA9 - 2568 - 000
1
SCREW,MACH.,TRUSS HEAD
3
FB1 - 0723 - 000
2
PAD, RUBBER
4
FB1 - 7281 - 000
1
ARM, SEPARATION
5
FB1 - 7284 - 000
1
ARM, SOLENOID
6
FB1 - 7285 - 000
1
ARM, PAPER PICK-UP SENSOR
7
FB1 - 9273 - 000
1
MOUNT, CARTRIDGE, REAR
8
FB1 - 9280 - 000
1
PLATE, SEPARATION ARM
9
FB2 - 9566 - 000
1
PLATE, GROUNDING 100V
10
FB2 - 9570 - 000
1
BLOCK, SHUTTER
11
FB2 - 9571 - 000
1
GRIP FC220,PC420
WHITE
FB2 - 9579 - 000
1
GRIP FC220,PC420
GRAY
12
FB2 - 9572 - 000
1
PLATE, TRANSFER TERMINAL
13
FB2 - 9573 - 000
1
SHEET, REGISTRATION
14
FB2 - 9574 - 000
1
GUIDE, TRANSFER, LOWER
15
FB2 - 9575 - 000
1
PLATE, CONTINUITY
16
FB2 - 9589 - 000
1
BUSHING
17
FB2 - 9622 - 020
1
HOLDER, DOOR SWITCH
18
FB2 - 9641 - 000
1
BELT, FAN
19
FB4 - 0048 - 000
1
PLATE, DOOR SWITCH LINK, 2
20
FB4 - 0055 - 000
2
SPRING, COMPRESSION
21
FB4 - 0301 - 000
1
KEY TOP, DENSITY CORRECTION
22
FF2 - 7829 - 000
1
VARISTOR
23
FF2 - 9928 - 000
1
CABLE, HEATER CONNECTOR J909
24
FF3 - 0150 - 000
1
VARISTOR
25
FF3 - 2663 - 000
1
INLET, AC 115/120/220/240V
26
FF3 - 2664 - 000
1
CABLE, GROUNDING 100V
27
FF5 - 1644 - 040
1
STATIC CHARGE ELIMINATOR
28
FF5 - 3660 - 000
1
ARM, LIFTER
