Canon PC430 - Page 214

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
102 -
28A
FB1 - 7283 - 000
1
SPRING, LEAF
28B
FB2 - 9590 - 000
1
SHEET, GUIDE
29
FF5 - 6411 - 000
1
COVER, PCB UNIT FC220,PC420 WHITE
FF5 - 6412 - 000
1
COVER, PCB UNIT FC220,PC420 GRAY
FB4 - 0297 - 000
1
COVER, PCB UNIT PC430 WHITE
29A
FB1 - 7467 - 000
1
SHEET, MESH FC220,PC420
30
FG5 - 4799 - 000
1
DELIVERY SENSOR PCB ASSEMBLY
30A
FF3 - 0148 - 000
1
CABLE, DELIVERY THERMISTOR J603,801,907
30B
WG8 - 0280 - 000
1
PHOTO-INTERRUPTER Q801
31
FG5 - 4808 - 000
1
MOTOR DRIVE SENSOR PCB ASS’Y J904
31A
WG8 - 0280 - 000
1
PHOTO-INTERRUPTER Q901
32
FG5 - 4815 - 000
1
TRANSFER ROLLER UNIT
33
FG5 - 9456 - 000
1
CONTROL PANEL PCB UNIT
33A
FH6 - 3815 - 000
1
LED, 7 SEGMENT LED601
34
FH2 - 5274 - 000
1
CORD, POWER SUPPLY 220V PTR,UTR,PTT
35
FH2 - 5276 - 030
1
CORD, POWER SUPPLY 240V RTM
36
FH2 - 6223 - 000
1
CABLE, FLAT J202,601
37
FH2 - 6427 - 000
1
CORD, POWER SUPPLY 100V
38
FH2 - 6488 - 000
1
CORD, POWER 220V PTS
39
FH9 - 0492 - 000
1
SOLENOID, DC24V SL1 J901
40
FS5 - 0436 - 000
1
GEAR, 29T/34T/38T
41
FS5 - 0437 - 000
1
GEAR, 22T
42
FS5 - 2332 - 000
1
SPRING, COMPRESSION
43
FS5 - 2333 - 000
1
SPRING, COMPRESSION
44
FS5 - 2334 - 000
1
SPRING, TENSION
45
RH2 - 5015 - 000
1
CORD, POWER SUPPLY 240V UTS
46
WC8 - 5058 - 000
1
MICROSWITCH, DOOR SW2
47
WT3 - 5021 - 000
1
CORD, POWER SUPPLY 115/120V
48
XA9 - 0767 - 000
2
SCREW,TP,M3X10 FC220,PC420
49
XA9 - 0938 - 000
1
SCREW,TP,M3X35
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
102-4
