FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
102 -
501
XB2 - 7300 - 607
2
SCREW,W/WASHER,M3X6
502
XB2 - 7300 - 607
1
SCREW,W/WASHER,M3X6 100V
503
XB4 - 7260 - 609
2
SCREW,TAPPING,TRUSS HEAD,2.6X6
504
XB4 - 7300 - 509
1
SCREW,TAPPING,TRUSS HEAD,M3X5
505
XB4 - 7300 - 809
1
SCREW,TAPPING,TRUSS HEAD,M3X8
506
XB4 - 7400 - 805
5
SCREW,TAPPING,TRUSS HEAD,M4X8
507
XB4 - 7401 - 009
2
SCREW,TAPPING,TRUSS HEAD,M4X10
508
XB4 - 7401 - 009
4
SCREW,TAPPING,TRUSS HEAD,M4X10
509
XB6 - 7300 - 409
1
SCREW,TP,M3X4
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
102-5
