Canon PC430 - Page 218

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
102A - NPN
RF
LOWER MAIN BODY FC200,PC400
1
FA9 - 2568 - 000
1
SCREW,MACH.,TRUSS HEAD 100V
2
FA9 - 2568 - 000
1
SCREW,MACH.,TRUSS HEAD
3
FB1 - 0624 - 000
2
ROLLER, PAPER PICK-UP
4
FB1 - 0723 - 000
2
PAD, RUBBER
5
FB1 - 8832 - 000
1
ROLLER, SLIP
6
FB1 - 8833 - 020
1
ARM, PAPER PICK-UP SENSOR
7
FB1 - 8835 - 000
4
SPRING, WIRE
8
FB1 - 9273 - 000
1
MOUNT, CARTRIDGE, REAR
9
FB2 - 9566 - 000
1
PLATE, GROUNDING 100V
10
FB2 - 9570 - 000
1
BLOCK, SHUTTER
11
FB2 - 9571 - 000
1
GRIP WHITE
FB2 - 9579 - 000
1
GRIP GRAY
12
FB2 - 9572 - 000
1
PLATE, TRANSFER TERMINAL
13
FB2 - 9574 - 000
1
GUIDE, TRANSFER, LOWER
14
FB2 - 9575 - 000
1
PLATE, CONTINUITY
15
FB2 - 9622 - 020
1
HOLDER, DOOR SWITCH
16
FB2 - 9641 - 000
1
BELT, FAN
17
FB4 - 0048 - 000
1
PLATE, DOOR SWITCH LINK, 2
18
FB4 - 0055 - 000
2
SPRING, COMPRESSION
19
FB4 - 0240 - 000
1
TRAY, MANUAL PAPER FEED 100V
WHITE
FB4 - 0241 - 000
1
TRAY, MANUAL PAPER FEED 100V
GRAY
FB4 - 0242 - 000
1
TRAY, MANUAL PAPER FEED 120/220/240V
WHITE
FB4 - 0243 - 000
1
TRAY, MANUAL PAPER FEED 120/220/240V
GRAY
20
FB4 - 0246 - 000
1
LINK, 5
21
FB4 - 0262 - 000
1
PLATE, LINK BLANKING
22
FF2 - 7829 - 000
1
VARISTOR
23
FF2 - 9928 - 000
1
CABLE, HEATER CONNECTOR J909
24
FF3 - 0150 - 000
1
VARISTOR
25
FF3 - 2663 - 000
1
INLET, AC 120/220/240V
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
102A-3
