FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
102A -
26
FF3 - 2664 - 000
1
CABLE, GROUNDING 100V
27
FF5 - 1644 - 040
1
STATIC CHARGE ELIMINATOR
28
FF5 - 6411 - 000
1
COVER, PCB UNIT WHITE
FF5 - 6412 - 000
1
COVER, PCB UNIT GRAY
28A
FB1 - 7467 - 000
1
SHEET, MESH
29
FG5 - 4799 - 000
1
DELIVERY SENSOR PCB ASSEMBLY
29A
FF3 - 0148 - 000
1
CABLE, DELIVERY THERMISTOR J603,801,907
29B
WG8 - 0280 - 000
1
PHOTO-INTERRUPTER Q801
30
FG5 - 4808 - 000
1
MOTOR DRIVE SENSOR PCB ASS’Y J904
30A
WG8 - 0280 - 000
1
PHOTO-INTERRUPTER Q901
31
FG5 - 4815 - 000
1
TRANSFER ROLLER UNIT
32
FG5 - 9504 - 000
1
CONTROL PANEL PCB UNIT
32A
FH9 - 0535 - 000
1
LED, SLA-380LT3F LED602
32B
FH9 - 0536 - 000
1
LED, SLA-380MT3F LED601
33
FH2 - 5274 - 000
1
CORD, POWER SUPPLY 220V PTQ,UTP
34
FH2 - 5276 - 030
1
CORD, POWER SUPPLY 240V RTL
35
FH2 - 6224 - 000
1
CABLE, FLAT J202,601
36
FH2 - 6427 - 000
1
CORD, POWER SUPPLY 100V
37
FH2 - 6488 - 000
1
CORD, POWER 220V PTV
38
FS1 - 9102 - 000
1
SCREW,STEPPED,M3
39
FS5 - 0464 - 000
1
GEAR, 27T
40
FS5 - 0465 - 000
2
GEAR, 39T
41
RH2 - 5015 - 000
1
CORD, POWER SUPPLY 240V UTQ
42
WC8 - 5058 - 000
1
MICROSWITCH, DOOR
43
WT3 - 5021 - 000
1
CORD, POWER SUPPLY 120V
44
XA9 - 0767 - 000
2
SCREW,TP,M3X10
45
XA9 - 0938 - 000
1
SCREW,TP,M3X35
501
XB2 - 7300 - 607
2
SCREW,W/WASHER,M3X6
502
XB2 - 7300 - 607
1
SCREW,W/WASHER,M3X6 100V
503
XB4 - 7300 - 509
1
SCREW,TAPPING,TRUSS HEAD,M3X5
