Canon PC430 - Page 233

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
810 - FG5 - 9536 - 000
1
FIXING ASSEMBLY 100V
FG5 - 9537 - 000
1
FIXING ASSEMBLY 115/120V
FG5 - 9539 - 000
1
FIXING ASSEMBLY 220V PTT
FG5 - 9614 - 000
1
FIXING ASSEMBLY 220V PTS,PTV
FG5 - 9538 - 000
1
FIXING ASSEMBLY 220V PTR,UTR,PTQ,UTP
240V
1
FB1 - 7333 - 000
1
SHEET, INSULATING
2
FB2 - 9601 - 000
1
ROLLER, PRESSURE
3
FB2 - 9603 - 000
1
SHEET, RELEASE ARM
4
FB2 - 9608 - 000
1
PLATE, INLET GUIDE
5
FB2 - 9610 - 000
1
GUIDE, PAPER DELIVERY, LOWER
6
FB2 - 9611 - 020
1
FAN, EXHAUST
7
FB2 - 9612 - 000
1
ROLLER, PAPER DELIVERY
8
FB2 - 9613 - 020
1
ARM, PAPER DELIVERY SENSOR
9
FB2 - 9614 - 000
1
ARM, DRIVE RELEASE
10
FB2 - 9616 - 000
1
PULLEY, FAN
11
FB2 - 9617 - 000
1
BUSHING
12
FB2 - 9625 - 000
2
CLAW, SEPARATION
13
FB2 - 9627 - 000
1
SHEET, WIND BLOCK
14
FB2 - 9653 - 000
1
LABEL, "CAUTION, HIGH TEMP." JAPANESE/ENGLISH
FRENCH
FB4 - 0365 - 000
1
LABEL, "CAUTION, HIGH TEMP." GERMAN/SPANISH/
ITALIAN
FC2 - 5845 - 000
1
LABEL, "CAUTION, HIGH TEMP." KOREAN
FB4 - 0370 - 000
1
LABEL, "CAUTION, HIGH TEMP." CHINESE
15
FB4 - 0049 - 000
1
SPRING, LEAF
16
FB4 - 0357 - 000
2
GUIDE, INLET, UPPER
17
FF5 - 6421 - 000
1
LINK, DOOR SWITCH, 1
18
FG5 - 4809 - 000
1
FIXING UPPER ASSEMBLY 100V
FG5 - 4810 - 000
1
FIXING UPPER ASSEMBLY 115/120V
FG5 - 4811 - 000
1
FIXING UPPER ASSEMBLY 220/240V
19
FS6 - 0337 - 000
1
GEAR, 22T
20
FS6 - 0339 - 000
1
GEAR, 32T
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
810-2
