FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
810 -
21
FS6 - 0340 - 020
1
GEAR, 22T
22
FS6 - 0962 - 000
1
GEAR, 12T
23
FS6 - 2163 - 000
2
SPRING, TENSION
24
FS6 - 2164 - 000
1
SPRING, COMPRESSION
25
RB1 - 3087 - 000
2
PIN
26
RB1 - 3090 - 000
2
BUSHING, PRESSURE ROLLER
27
RH2 - 5336 - 000
1
CONNECTOR, DC SEE NOTE
J907
28
RS5 - 2223 - 000
2
SPRING, PRESSURE
29
XA9 - 0233 - 000
1
SCREW,W/WASHER,M3X6
501
XB1 - 2300 - 409
5
SCREW,MACH.,TRUSS HEAD,M3X4
502
XD1 - 1106 - 239
1
SHIM
503
XD2 - 1100 - 322
2
RING,E
504
XD2 - 1100 - 502
1
RING,E
COPYRIGHT © 1998 CANON INC. CANON FC220/PC420/430/FC200/PC400 REV.0 JAN. 1998 PRINTED IN JAPAN [IMPRIME AU JAPON]
810-3
