Canon PC430 - Page 236

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
910 - FG5 - 9450 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y FC220 100V
FG5 - 9458 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y FC220 115V
FG5 - 9452 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y FC220 220/240V
FG5 - 9451 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y PC420,430 120V
FG5 - 9500 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y FC200 100V
FG5 - 9502 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y FC200 220/240V
FG5 - 9501 - 000
1
DC CON./DC P. SUPPLY PCB ASS’Y PC400 120V
1
FB1 - 7424 - 020
1
HOLDER, H.V.T.
2
FB1 - 7425 - 000
1
PIN CONTACT
3
FB1 - 7427 - 000
3
SPRING, COMPRESSION
4
FB1 - 7430 - 000
1
PIN CONTACT
5
FB1 - 7431 - 000
1
PIN CONTACT
6
FB2 - 9647 - 000
1
SHEET, CABLE PROTECTIVE SEE NOTE
7
FF2 - 7814 - 000
1
CABLE, TRANSFER CONTINUITY
FU101
VD7 - 0042 - 501
1
FUSE, 250V, 2.5A 100/115/120V
VD7 - 0641 - 601
1
FUSE, 250V, 1.6A 220/240V
FU102
VD7 - 0211 - 002
1
FUSE, 125V, 10A 100/115/120V
VD7 - 0645 - 001
1
FUSE, 250V, 5A 220/240V
J101
FF2 - 9932 - 000
1
CABLE, FIXING AC CONTINUITY, H
J102
FF2 - 9933 - 000
1
CABLE, FIXING AC CONTINUITY, N
J103
FF3 - 2671 - 000
1
CABLE, AC, N
J104
FF3 - 2673 - 000
1
CABLE, AC, H
J108
FF3 - 2677 - 000
1
CABLE, LAMP
J201
FF3 - 2665 - 000
1
CABLE, HIGH VOLTAGE, 1 FC220,PC420,430
MAGENTA
FF3 - 2666 - 000
1
CABLE, HIGH VOLTAGE, 1 FC200,PC400
MAGENTA
JP1
FF3 - 2669 - 000
1
CABLE, HIGH VOLTAGE, 3 BLACK
JP2
FF3 - 2667 - 000
1
CABLE, HIGH VOLTAGE, 2 RED
L101
FH9 - 0491 - 000
1
FILTER, NOISE 100/115/120V
FH7 - 9218 - 000
1
COIL, SC 220/240V
L102
FH7 - 9219 - 000
1
COIL, SU 220/240V
