Canon PC430 - Page 237

FIGURE
&
KEY NO.
PART NUMBER
R
A
N
K
Q’
T
Y
DESCRIPTION SERIAL NUMBER / REMARKS
910 -
L302
FH7 - 9238 - 000
1
COIL, SN 100V
FH9 - 0490 - 000
1
COIL, SN 115/120V
FH7 - 9220 - 000
1
COIL 220/240V
Q144
FH4 - 1303 - 000
1
IC, UPD18001CW-531, MPU FC220,PC420,430
FH4 - 1304 - 000
1
IC, UPD18001CW-532, MPU FC200,PC400
R268
FH4 - 9157 - 000
1
RESISTOR, 4MOHM, 1/4W
R271
FH4 - 9156 - 000
1
RESISTOR, 2MOHM, 1/2W
R274
FH4 - 9196 - 000
1
RESISTOR, 1.2MOHM, 1W
R285
FH4 - 9195 - 000
1
RESISTOR, 40MOHM, 0.69W
R307
FH4 - 9195 - 000
1
RESISTOR, 40MOHM, 0.69W
RL101
FH9 - 0466 - 000
1
RELAY
SQ101
RH6 - 3434 - 000
1
FILTER, NOISE
T101
FH3 - 0749 - 000
1
TRANSFORMER 100/115/120V
FH3 - 0753 - 000
1
TRANSFORMER 220/240V
T102
FH3 - 0751 - 000
1
TRANSFORMER
T103
FH3 - 0856 - 000
1
TRANSFORMER
T104
FH3 - 0746 - 000
1
TRANSFORMER
T105
FH3 - 0750 - 000
1
TRANSFORMER 100/115/120V
FH3 - 0755 - 000
1
TRANSFORMER 220/240V
T106
FH3 - 0850 - 000
1
TRANSFORMER 100/115/120V
FH3 - 0851 - 000
1
TRANSFORMER 220/240V
T107
FH3 - 0638 - 000
1
TRANSFORMER
