Settings back side What to enter
[X offset ({0})] The image is shifted in X direction (feed direc-
tion) in mm (inches).
A shift > 0 moves the image to the right-hand
side (trailing edge):
• The distance between the leading edge of
the sheet and the image on the sheet increa-
ses.
• The distance between the trailing edge of
the sheet and the image on the sheet de-
creases.
• The dots on the verification chart move to
the right-hand side (trailing edge).
A shift < 0 moves the image to the left-hand
side (leading edge):
• The distance between the leading edge of
the sheet and the image on the sheet de-
creases.
• The distance between the trailing edge of
the sheet and the image on the sheet increa-
ses.
• The dots on the verification chart move to
the left-hand side (leading edge).
[Z offset ({0})]
The image is shifted in Z direction (perpendic-
ular on the feed direction) in mm (inches).
A shift > 0 moves the image to the top of the
sheet:
• The distance between the top of the sheet
and the image on the sheet decreases.
• The dots on the verification chart move to
the top of the sheet.
A shift < 0 moves the image to the bottom of
the sheet:
• The distance between the top of the sheet
and the image on the sheet increases.
• The dots on the verification chart move to
the bottom of the sheet.
Ranges
Setting
Range (mm) Range (inches)
[X offset ({0})] -5.0 to +5.0 -0.197 to +0.197
[Z offset ({0})] -2.5 to +2.5 -0.098 to +0.098
NOTE
If the shift is too much, the image be printed over the edges of the sheet.
• Risk of reprinting.
• Risk of system pollution.
Values for the Media Registration
104
Chapter 5 - Media Handling
Canon varioPRINT 135 Series
