CDE360 Vector Control AC Drive Chapter 6 Parameters Description
Table 6- 11 Relation table of analog value and pulse output
Value
Function
Range
0
Setting frequency
0~Max frequency(b0.00)
1
Running frequency
0~Max frequency(b0.00)
2
Output current
0~2 times motor rated current
3
Output voltage
0~1.2 times motor rated voltage
4
Output power
0~2 times motor rated power
5
Output torque
0~2 times motor rated torque
6
AI1
0V~10V（or 0~20mA）
7
AI2
0V~10V（or 0~20mA）
8
AI3
0V~10V（or 0~20mA）
9
X6/FI
0.00kHz~100.00kHz
10
Target torque
0~2 times motor rated torque
11
PID setting
0.0%~100.0%
12
PID feedback
0.0%~100.0%
13
PID output
0.0%~100.0%
14
Actual length
0~Sett length(E7.07)
15
Count value
0~Set count value(E7.05)
16
Communication setting
0.0%~100.0%
17
Feedback frequency
0~Max frequency(b0.00)
C3.04
Range: 11~22
Default: 21
AO curve
selection
AO curve specified the relationship between the output percentage and
analog output signal.
Provide two AO curves. Parameters’ edit according to digit
1: AO curve 1(Two points,Refer to C3.05～C3.08)
2: AO curve 2(Four points,Refer to C3.09～C3.12)
Unit’s digit: AO1 Ten’s digit: AO2
C3.05
Range: 0.00~10.00
Default: 0.00
AO curve 1
minimum output
Unit: V
Define AO curve 1 minimum output value. When chose the 0~20mA
current input, 0mA corresponding to the 0V, and 20mA corresponding to
10V.
C3.06
Range: 0.0~C3.08
Default: 0.0
Corresponding
setting of AO
curve 1 minimum
output
Unit: %
The relationship between AO curve 1 minimum input signal and the
percentage of set value.
