CDE360 Vector Control AC Drive Chapter 7 Fault Detection and Diagnostics
Display
Fault Name
Possible Causes
Solutions
Er/AL27
Motor
overheat
The cabling of the temperature
sensor becomes loose.
Check the temperature sensor
cabling and eliminate the
cabling fault.
The motor temperature is too high.
Lower the carrier frequency or
adopt other heat radiation
measures.
Er28
Motor short
circuit to
ground fault
The motor is short circuited to the
ground.
Replace the cable or motor.
Er/AL29
External fault
External fault signal is input via DI.
Check the DI input signal.
Er30
Keypad
communicati
on fault
The communication of keypad with
drive is abnormal.
Check the line connecting the
control board and the keypad.
Er/AL31
RS485
communicati
on fault
The communication of RS485 field
with drive is abnormal.
Check the line and the
communication device.
Er/AL32
Optional card
communicati
on fault
The communication of optional
card with external device is
abnormal.
Check the line and the optional
card.
Er33
Optional card
connection
fault
The communication of optional
card with control board is
abnormal.
Check the line and the optional
card.
Er34
Auto tune
fault
The cable connection of the motor
are abnormal.
Check the cable connecting the
drive and the motor.
Tune when motor is rotating.
Tune when motor is stops.
The motor parameters are not set
according to the nameplate.
Set the motor parameters
according to the nameplate
properly.
Er/AL35
PID feedback
over range
The PID feedback is higher than
the setting of E5.33 or lower than
the setting of E5.34.
Check the PID feedback signal
or set E5.33 and E5.34 to a
proper value.
The parameters of PID are set
incorrectly.
Set the PID parameters
properly.
Er36
EEPROM
R/W fault
EEPROM is damage.
Contact with technical service.
Er37
Parameter
setting fault
Parameter R/W fault.
Press STOP/RST to reset the
drive or Contact with technical
service.
