CDE360 Vector Control AC Drive Chapter 3 Mechanical and Electrical Installation
-35-
high-speed pulse (0～100KHz) output.
Relay Output
TB1（~TA1）
T1 normally close terminal
1) TA1 is used for the common port the relay T1
and TA2 is used for the common one of the
relay T2.
2) Contactor driving ability:
AC 250V,3A,COSΦ=0.4；DC 30V,1A.
TC1（~TA1）
T1 normally open terminal
TB2（~TA2）
T2 normally close terminal
TC2（~TA2）
T2 normally open terminal
Communication
485+
The positive terminal of
RS485 differential signal
RS485 communication between the upper machine
and the AC drive.
485-
The negative terminal of
RS485 differential signal
Shielding
Shielding earthing
Connect it to shielding earthing of the signal cable.
Auxiliary
interface
J4
The interface of the external
cards
20 terminals, which are used for connecting the
external cards with special functions.
