Model 201 Installation & Technical
8400-M117-O1 Rev D
Software selectable Non-isolated
0-10 VDC or 4-20mA DC
(1) Non-isolated 0-10 VDC output
(12 bit, 2k ohm min.)
(1) Non-isolated 4-20mA DC output
(12 bit, 450 ohm max.)
1.1 Standard Features
Push button tare function
Gross, tare, net conversion
Hi-Resolution mode
StableSENSE
® 1
adjustable digital filtering
Gross and Net accumulators
Single serial port
Remote input line for Zero, Tare, Gross and Print (1000
feet maximum)
SMA level 2 compliant serial communications (For more
information see http://www.scalemanufacturers.org)
Field re-programmable via PC interconnection
Test feature (performs display)
1.2 Optional Features
Remote Display
1.3 Approvals
Class III NTEP – Certificate of Conformance No. 13-028
Class III Measurement Canada – Approval No. AM-5904C
1
StableSENSE
®
is a digital filter utilizing proprietary software algorithms to
remove or greatly reduce changes in the weight display resulting from
movement on the scale platform. StableSENSE
®
can be used to lessen
the effects of movement on the scale or to lessen the effects of wind
and vibration. Any application affected by vibration or movement on the
scale platform can benefit using StableSENSE
®
.
