Model 201 Installation & Technical
8400-M117-O1 Rev D
5.18 Display High Resolution Weight
IMPORTANT! The Hires mode requires a load of 10% of Capacity
on the scale.
Hi res
With Hires displayed, press the F3/ key. The display will change to HirES=.
Proceed to the HirES= (Display High Resolution) parameter.
Hires= (Display High Resolution)
1. With HirES= displayed, press the F3/ key.
2. The display will change to no.
3. If you wish to skip high resolution weight display and return to the
SETUP mode, press the F3/ key again.
4. Otherwise, place a calibrated test weight on the scale and press the
F2/ key to toggle to yes and then press the F3/ key.
5. The display will change to show the amount of the test weight in
"high resolution" mode (1/10 division), and an H will be displayed to
the right of the displayed weight.
6. Press the F3/ key to exit the Display High Resolution Weight and
return to the normal operation mode.
