Model 201 Installation & Technical
8400-M117-O1 Rev D
4.7.2 Multi-Point Calibration
Up to 5 calibration points (CAL1=through CAL5=) may be displayed depending
on the value set for the CALPt= parameter. Note that one of the weights must
be 0 (no load).
NOTE: The following outlines the steps to perform calibration when 2 calibration
points have been selected for the CALPt= parameter.
CAL1= – First Calibration Weight
1. The display will show CAL1=. This is the first of three calibration
weights. This weight could be ZERO (NO LOAD) or the TEST
WEIGHTS (TEST LOAD).
2. Press the F3/ key to view the current setting.
3. If the first calibration weight is to be ZERO (NO LOAD), press the
F3/ key.
4. If the first calibration weight is to be the TEST WEIGHTS (TEST
LOAD), use the F1/ and F2/ keys to input the value of the test
weights.
5. Place the weights on the scale platform, then press the F3/ key.
6. Starting at the left and proceeding right, a series of dashes will
appear on the display.
7. Next, starting at the left and proceeding right, the dashes will
disappear, after which the display will show: CAL2=.
CAL2= – Second Calibration Weight
1. The display will show CAL2=. This is the second of three calibration
weights. This weight could be a PARTIAL amount of the TEST
WEIGHTS (TEST LOAD).
2. Press the F3/ key to view the current setting.
3. If the second calibration weight is to be a PARTIAL amount of the
TEST WEIGHTS (TEST LOAD), use the F1/ and F2/ keys to
input the value of the test weights.
4. Place the weights on the scale platform, then press the F3/ key.
5. Starting at the left and proceeding right, a series of dashes will
appear on the display.
6. Next, starting at the left and proceeding right, the dashes will
disappear, after which the display will show: CAL3=.
