Cardinal 201 User Manual

Model 201 Installation & Technical
8400-M117-O1 Rev D
Page 59
5.7 Ethernet Port
Ether
With Ether displayed, press the F3/  key. The display will change to enAbl=.
Proceed to the enAbl= (Enable Ethernet Port) parameter.
enaBl= (Enable Ethernet Port)
Press the F3/  key to show the current setting. If the setting displayed is
acceptable, press the F3/  key again to save it. Otherwise, use the
F2/ key to toggle to a new setting and then press the F3/  key to save
it. Allowable settings are:
off
Off (Ethernet port is Disabled)
on
ON (Ethernet port is Enabled)
dHCP= (Enable DHCP)
Press the F3/  key to show the current setting. If the setting displayed is
acceptable, press the F3/  key again to save it. Otherwise, use the
F2/ key to toggle to a new setting and then press the F3/  key to save
it. Allowable settings are:
off
Off (DHCP is Disabled)
on
ON (DHCP is Enabled)
NOTE: If dHCP= (Enable DHCP) is disable (oFF), the following
prompts, IP address, Netmask, Gateway and DNS will be active.
1p1= (IP Address, First Part)
The format for an IP address is: ## . # . # . ## (e.g., 90.1.2.68). This
parameter is the first part of the address.
Press the F3/  key to view the current setting for the first part of the IP
address. If the displayed setting is acceptable, press the F3/  key to
save it. Otherwise, use the F2/ and F1/ keys to enter a new setting
and press the F3/  key to save the new setting. Allowable values are:
000 through 255.
